Experiences testing large machines with high-voltage partial-core transformers


Dr Andrew Lapthorn
University of Canterbury

For many reasons, such as commissioning, maintenance and performing investigations; it may be necessary to perform high-voltage tests on large rotating plant. These tests can include, partial discharge investigations, insulation power factor and ac withstand tests or high potential testing. To perform these tests the stator’s insulation needs to be raised to a high voltage.

This can be challenging as the stator’s insulation capacitance can be significant and requires large amounts of reactive power to energise, which can put a strain on the current capacity of the low voltage distribution board. Often reactive power compensation in the form of high-voltage tuneable inductors is required adding complexity and costs to the testing. At the University of Canterbury we have developed a unique solution to this problem in the form of a high-voltage partial-core transformer. This presentation will discuss the development of this technology as well as highlight its application on several sites in New Zealand and Australia.
